About – PowerKey4Revit

Tools to help using Revit easier and more enjoyable. They will speed up your production rate by combining multiple commands to a single Keyboard Shortcut. So you work faster on the simple drawing and annotation tasks you use every day. These improve your Revit Drawing Speed rather than BIM speed and these are the core commands you use all the time. Thank you for taking the time to look at my products.



  • Speed up the tedious stuff and enjoy designing and documentation more
  • Works in all versions of Revit
  • All updates available for anyone with valid license

PowerKey4Revit Commands

Current commands/scripts and Keyboard Shortcuts

Description Keyboard Shortcut SpeedKey
w1 Select text, arrow left w1 +F13 + = Shift Key
w2 Select text, arrow last remove w2 +F14 ^= Control Key
w3 Select text, arrow right TOP w3 +F15 != Alt key
w4 Select text, curved arrow left w4 +F16 #= Window Key
w5 Select text, curved arrow right w5 +F17
w6 Select text, Move arrow right TOP to Bottom w6 +F18
rev Revision cloud 2 points and tag rev +F19 so:
ce Ceiling 2 points ce +F20 #NAME?
g(spacebar) region, 2 points g(spacebar) +F21 ^F13= Control + F13
m(spacebar) mirror objects draw axis NO COPY   m(spacebar) +F22 !F13= Alt + F13
og Select all ELEMENTS of type & over-ride graphics og +F23 #F13= WinKey + F13
oh Reset Selected  ELEMENTS of type & Reset over-ride graphics oh +F24
nn Note from file w/ list (Set arrow values in ini file) nn ^F13
sn Schedule Note from file w/ list   sn ^F14
r1 Rotate objects 90° (clockwise) r1 ^F15
r2 Rotate objects 180°   r2 ^F16
r3 Rotate objects 270° (clockwise) or 90° (anticlockwise) r3 ^F17
pp Arch GUI note w/text  (Set arrow values & Units in ini file) pp ^F18
lp Duct GUI Note w/text  (Set arrow values & Units in ini file) lp ^F19
66 Pipe GUI Note w/text  (Set arrow values & Units in ini file) 66 ^F20
rr1 VG- from file rr1 ^F21
rr2 VG- Room InFill & RefToggle rr2 ^F22
rr3 VG- Room Sep Line Toggle rr3 ^F23
cei ceiling 2 points cei
rev rev cloud rectangular with rev tag rev
wsn workset new list from file wsn #F24
sb Search Project Browser, add input and then press.{esc}{tab} sb #F15
sd Search Project Browser sd ^!F13
symbol Ø deg(spacebar) ^F24
symbol ° dia(spacebar) !F13
symbol ½ 1/2(spacebar) !F14
symbol ¼ 1/4(spacebar) !F15
symbol ¾ 3/4(spacebar) !F16
symbol ⅛ 1/8(spacebar) !F17
symbol ⅜ 3/8(spacebar) !F18
symbol ⅝ 5/8(spacebar) !F19
symbol ⅞ 7/8(spacebar) !F20
symbol ⅓ 1/3(spacebar) !F21
symbol ⅔ 2/3(spacebar) !F22
symbol ≈ @(spacebar) !F23
symbol ∠ ang(spacebar) !F24
symbol ± +-(specebar) #F13
symbol ℄ cl(spacebar) #F14
symbol ₪ gf(spacebar)
symbol ℃ degC(spacebar) #F16
symbol ℉ degF(spacebar) #F17
symbol ⬆ aup(spacebar) #F18
symbol ⬇ adn(spacebar) #F19
symbol ➡ art(spacebar) #F20
symbol ⬅ alf(spacebar) #F21
symbol ✅ tik(spacebar) #F22
symbol ❌ rx(spacebar) #F23
Other
hlp Opens List of PowerKeys in Revit
SSSS Opens User.ini file in Notepad
7777 Opens Frequency.ini file in Notepad
F3 Suspend PowerKey4Revit F3
F4 Toggle PowerKey4Revit On F4
cooo Starts Tooltip Coordinates.exe
Win+1 Toggle coordinates on/off
choo Starts Crosshairs.exe
Win+2 Toggle crosshairs on/off
Win+3 Toggle crosshairs Lock position on/off
